Stone mill is a kind of machine that can grind flour, bean powder and buckwheat powder. Nowadays, most of flour and bean powder are grinded by modern machines. Compared with traditional grinding, the nutritional value is much lower. As people pay more and more attention to health preservation, many people choose to buy small domestic stone mills and grind them at home. Because of their small size, they can grind them out With the advantages of delicious food, high nutritional value, and easy to use, Zhongyang stone mill company has been sought after by the vast number of consumers, and the number of purchased products is also increasing. One of the more important accessories in the stone mill equipment is the grinding plate, and the role of grinding plate is also very large. How much do you know about the process of changing grinding plate? Zhongyang stone mill company has made a decision on the process of changing grinding plate Detailed answers.

一、打開機器前端的防護罩，取下動磨盤，用螺絲刀擰緊固定磨片的螺絲，取出磨片。

1、 Open the protective cover at the front end of the machine, take down the movable grinding plate, tighten the screw fixing the grinding plate with a screwdriver, and take out the grinding plate.

二、把新的磨片裝回舊磨片原來的位置，鎖上所有螺絲，但不要擰緊。接下來，觀察磨片的內部圓形和設置臺階之間的間隙，觀察磨片和電機是否同心，調整所有螺絲，確定沒有問題，并逐步擰緊三個螺絲，不能擰緊螺絲，均勻地擰緊螺絲，直到鎖緊。只要

2、 Put the new grinding disc back into the original position of the old grinding disc and lock all screws, but do not tighten them. Next, observe the gap between the inner circle of the grinding plate and the setting steps, observe whether the grinding plate and the motor are concentric, adjust all the screws to make sure there is no problem, and gradually tighten the three screws. If the screws cannot be tightened, tighten the screws evenly until they are locked. as long as

三、完成以上步驟后，再按以下步驟操作：

3、 After completing the above steps, follow these steps:

1、將已經更換磨片的動磨片裝回磨粉腔，將機體上的調整螺絲以逆時針方式旋轉調松，然后蓋上機器前蓋鎖緊。

1. Install the moving grinding plate that has been replaced back into the grinding chamber, rotate the adjusting screw on the machine body in a counterclockwise manner to loosen, and then close the front cover of the machine and lock it.

家用小型石磨更換磨片的流程

The process of replacing grinding plate of small domestic stone mill

2、啟動家用石磨，按順時針方式旋緊調整螺絲，到機器因磨片摩擦發出尖銳聲音為止。然后令磨粉機自行空轉兩分鐘后方關閉機器。

2. Start the domestic stone mill and tighten the adjusting screw clockwise until the machine makes a sharp noise due to the friction of the grinding plate. Then turn off the mill after idling for two minutes.

3、然后再次打開機器前端蓋，取出動磨盤，仔細觀察并觸摸動磨盤和靜磨盤齒槽之間的摩擦痕跡，看磨盤周圍的摩擦痕跡是否均勻分布，摸磨盤周圍的溫度是否均勻。如果所有的差異都不明顯，那么安裝是平衡的，并且磨盤已經被成功地更換。

3. Then open the front cover of the machine again, take out the moving grinding plate, carefully observe and touch the friction marks between the teeth of the moving grinding plate and the static grinding plate, see whether the friction marks around the grinding plate are evenly distributed, and touch whether the temperature around the grinding plate is uniform. If all the differences are not obvious, then the installation is balanced and the disc has been successfully replaced.

4、若是摩擦痕跡與觸手溫度不均勻，則證明家用小型石磨沒有安裝平衡，需要進行一些補救。此時，購買磨粉機時隨機器配送的銅片即可起到作用，若銅片已丟失則可自行尋找其他材料薄片替代，厚度以0.3mm為宜。觀察無摩擦痕跡或無溫度的地方有多長，然后根據其長度裁剪磨片，稍微旋松相關位置的螺釘，將薄銅片放在家用磨片的底部，調整磨片的中間度，然后擰緊螺釘。溫馨提示：動磨片與靜磨片均可如此操作。

4. If the friction trace and the temperature of the tentacle are not uniform, it proves that the household small stone mill is not balanced and needs to be remedied. At this time, the copper sheet delivered with the machine when purchasing the grinder can play a role. If the copper sheet has been lost, you can find other material sheet to replace it, and the thickness should be 0.3mm. Observe the length of the place without friction trace or temperature, then cut the grinding plate according to its length, slightly loosen the screw at the relevant position, put the thin copper plate at the bottom of the household grinding plate, adjust the intermediate degree of the grinding plate, and then tighten the screw. Warm tips: both dynamic and static grinding plates can be operated in this way.

5、按原方法再次試機，直將磨片調整到平衡為止。

5. Test the machine again according to the original method until the grinding plate is adjusted to balance.

6、新磨片更換成功后，可使用新細沙與大米一斤作為磨合新機物料，將其投入漏斗，將調節螺絲調九分緊程度。然后開機磨合四五遍即可。

6. After the new grinding plate is replaced successfully, the new fine sand and a jin of rice can be used as the running in materials of the new machine, put them into the funnel, and adjust the adjusting screw to the nine point tight degree. Then turn on and run in four to five times.

7、相關工作完成，可洗凈機器，此宣告更換磨片完成。

7. After the relevant work is completed, the machine can be cleaned, and the replacement of grinding plate is declared to be completed.
